Unit · AXIAL-PISTON PUMP
A8VO107SR/60R1+AA10VO100DFLR+AZPF-11R902016796
Axial piston pump Bosch Rexroth series A8VO, type code A8VO107SR/60R1+AA10VO100DFLR+AZPF-11, material number R902016796. Axial piston unit: bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar (A8V). Operating mode: double pump (parallel design), open circuit (O).
- Number
- R902016796
- Type code
- A8VO107SR/60R1+AA10VO100DFLR+AZPF-11
- Group
- A10VO 100
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909603048 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| 18 | R909086139 | HEXAGON SCREW | 2 | |
| 19 | R909430408 | WASHER | 2 | |
| 50 | R902433578 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | |
| 55 | 0510525072 | HYDRAULIC GEAR PUMPL | 1 | |
| 56 | R909083058 | SOCKET HEAD CAP SCREW | 2 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar | A8V |
| Operating mode | Double pump (parallel design), open circuit | O |
