Unit · AXIAL-PISTON PUMP
AA10VO45ED72/52L-VCA11N00P-S3273R902488371
Axial piston pump Bosch Rexroth series A10VO, type code AA10VO45ED72/52L-VCA11N00P-S3273, material number R902488371. Nominal size: NG 45. Axial piston unit: swashplate design, variable, nominal pressure 250 bar (3600 psi), maximum pressure 315 bar (4550 psi) (A10V). Operating mode: pump, open circuit (O). Control device: electric U = 24 V (ED72). Direction of rotation: viewed on drive shaft counter-clockwise (L). Sealing material: FKM (fluorocarbon rubber) (V). Drive shaft: tapered keyed shaft and UNF threaded bolt not for through-drive (C). Mounting flange: based on ISO 3019-2 (ISO) 2-hole (A). Working port: SAE flange ports fastening thread metric rear according to ISO 6162 metric not for through drive (11). Through drive: without through drive (N00). Connector for solenoids: DEUTSCH – molded connector, 2-pin – without suppressor diode (for electric controls) (P). Special version no. 3273.
- Number
- R902488371
- Type code
- AA10VO45ED72/52L-VCA11N00P-S3273
- Group
- A10VO 45
- Edition
- 06/2020
This parts list has no drawing.
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| 1 | R902488063 | BASE UNIT Assembly parts list →L | 1 | |
| 2 | R902485373 | CONTROL VALVE Assembly parts list →L | 1 | |
| 7 | R902650500 | SOCKET HEAD CAP SCREW | 4 | |
| 8 | R902434482 | SEAL | 1 | |
| 9 | R909831568 | SAFETY CAP | 1 | |
| 13 | R902488372 | INTERMEDIATE PLATE Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 250 bar (3600 psi), maximum pressure 315 bar (4550 psi) | A10V |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 45 | 45 |
| Control device | electric U = 24 V | ED72 |
| Series | Series 5, index 2 | 52 |
| Direction of rotation | Viewed on drive shaft counter-clockwise | L |
| Sealing material | FKM (fluorocarbon rubber) | V |
| Drive shaft | Tapered keyed shaft and UNF threaded bolt not for through-drive | C |
| Mounting flange | Based on ISO 3019-2 (ISO) 2-hole | A |
| Working port | SAE flange ports fastening thread metric rear according to ISO 6162 metric not for through drive | 11 |
| Through drive | Without through drive | N00 |
| Connector for solenoids | DEUTSCH – molded connector, 2-pin – without suppressor diode (for electric controls) | P |
