Assembly
ROTARY GROUPR902028969
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| 1 | R909421300 | CYLINDER | 1 | |
| R909650842 | CONTROL PLATE | 1 | ||
| R902027197 | CENTER PIN | 1 | ||
| R902021919 | PISTON | 7 | ||
| 5 | R909411104 | WASHER | 1 | |
| R902096612 | ADJUSTMENT SHIM Assembly parts list →L | 1 | ||
| R902027213 | COMPRESSION SPRING | 1 | ||
| 11 | R909444061 | RETAINING PLATE | 1 | |
| R902603052 | PAN-HEAD SCREW | 7 |
