Assembly
CONTROLR902211317
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902062441 | POSITIONING PISTON Assembly parts list →L | 1 | ||
| R909083034 | SOCKET HEAD CAP SCREW | 4 | ||
| R909154918 | HEXAGON NUT | 1 | ||
| R902600750 | ROD GUIDANCE RING | 2 | ||
| R902600194 | ROD SEALD | 2 | ||
| R902025915 | COVER | 1 | ||
| R909083782 | O-RINGD | 1 | ||
| R909083041 | SOCKET HEAD CAP SCREW | 4 | ||
| 41 | R909156305 | O-RINGD | 1 | |
| R902603485 | SLIDE GATE VALVE | 1 |
