Assembly
FLUSH/BOOST PRESSURE VALVER902228760
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902228762 | FLUSHING VALVE HOUSING | 1 | ||
| R902188370 | FLUSHING PISTON | 1 | ||
| R902161686 | SCREW PLUG | 2 | ||
| R909417112 | WASHER | 2 | ||
| R902011921 | COMPRESSION SPRING | 2 | ||
| R909419422 | VALVE SPOOL | 1 | ||
| R902161687 | SCREW PLUG | 1 | ||
| R909417848 | COMPRESSION SPRING | 1 | ||
| R909083065 | SOCKET HEAD CAP SCREW | 4 | ||
| R909831320 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909086435 | O-RING | 2 | ||
| R909083753 | O-RING | 3 | ||
| R909830861 | O-RING | 1 | ||
| R909157079 | SHIM RING | 1 | ||
| R909157965 | SHIM RING | 1 | ||
| R909157966 | SHIM RING | 1 | ||
| R909083769 | O-RING | 1 |
