Assembly
REGULATORR902254371
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909607171 | CONTROL ELEMENT Assembly parts list →L | 1 | ||
| R902159014 | CONTROL ELEMENT Assembly parts list →L | 1 | ||
| R902118422 | MEASURING PISTON Assembly parts list →L | 1 | ||
| R902254359 | CONTROL ELEMENT Assembly parts list →L | 1 | ||
| R902159097 | CONTROL HOUSING | 1 | ||
| R902134005 | ANGLE LEVER | 1 | ||
| R909440788 | BEARING BOLT | 1 | ||
| R909431286 | BUSHING | 1 | ||
| R909083050 | SOCKET HEAD CAP SCREW | 2 | ||
| R913009676 | STRAIGHT PIN | 2 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 7 | ||
| R901188705 | PROPORTIONAL PRESSURE RELIEF VALVE | 1 | ||
| R909083044 | SOCKET HEAD CAP SCREW | 3 | ||
| R909153364 | SCREW PLUG | 1 | ||
| R909087248 | RETAINING RING | 1 | ||
| R913045130 | O-RING | 1 | ||
| R909154024 | SCREW PLUG | 2 | ||
| R909151979 | SCREW PLUG | 1 | ||
| R909156492 | NOZZLE | 1 | ||
| R909156493 | NOZZLE | 1 | ||
| 98 | R902002475 | SEAL KIT | 1 |
