Assembly
CONNECTION PLATER902445997
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902438946 | INTERMEDIATE PLATE | 1 | ||
| R910514985 | O-RING | 4 | ||
| R910914340 | O-RING | 1 | ||
| R909151979 | SCREW PLUGD | 3 | ||
| R910938084 | DOUBLE BREAK-OFF PLUGD | 1 | ||
| R910121266 | SOCKET HEAD CAP SCREW | 6 |
Assembly
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902438946 | INTERMEDIATE PLATE | 1 | ||
| R910514985 | O-RING | 4 | ||
| R910914340 | O-RING | 1 | ||
| R909151979 | SCREW PLUGD | 3 | ||
| R910938084 | DOUBLE BREAK-OFF PLUGD | 1 | ||
| R910121266 | SOCKET HEAD CAP SCREW | 6 |
