Assembly
BASE UNITR902494201
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902494200 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R902419377 | PUMP HOUSING | 1 | ||
| R902444526 | CONNECTION PLATE | 1 | ||
| R902516002 | INDICATING DEVICE | 1 | ||
| R902519529 | STUD BOLT | 1 | ||
| R902402475 | COVER Assembly parts list →L | 1 | ||
| R910970213 | SOCKET HEAD CAP SCREW | 8 | ||
| R902650452 | SCREW PLUG | 3 | ||
| R909156649 | SCREW PLUG | 3 | ||
| R910901969 | SCREW PLUGD | 1 | ||
| R910948940 | O-RINGD | 1 | ||
| R913028081 | AXIAL SEAL | 2 | ||
| R910923835 | R-RINGD | 2 | ||
| R909831319 | DOUBLE BREAK-OFF PLUG | 2 | ||
| R910938084 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R910984830 | THROTTLE SCREW | 1 | ||
| R910970351 | THROTTLE SCREW | 1 | ||
| R910969260 | THROTTLE SCREW | 1 | ||
| R910978403 | THROTTLE SCREW | 1 | ||
| R909156651 | SCREW PLUG | 2 | ||
| R910979853 | REFERENCE PLATE | 1 | ||
| R902470376 | CONNECTING BLOCK Assembly parts list →L | 1 |
