Assembly
COVERR910594784
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| 50 | R910579815 | COVER | 1 | |
| 50 | R910582727 | PISTON | 1 | |
| 52 | R910579459 | THROTTLE SCREW | 1 | |
| 61 | R910120367 | SOCKET HEAD CAP SCREW | 6 | |
| 61 | R910100773 | SPRING LOCK WASHER | 6 | |
| 61 | R909831320 | DOUBLE BREAK-OFF PLUG | 1 | |
| 61 | R910977037 | O-RINGD | 2 | |
| 62 | R910584983 | O-RINGD | 1 | |
| 62 | R910584975 | O-RINGD | 1 | |
| 62 | R909151979 | SCREW PLUGD | 1 | |
| 62 | R909153816 | SCREW PLUGD | 2 |
