Unit · AXIAL-PISTON PUMP
A8VO107LR3H1+A4FO40+A4FO22+A10VO28DRR909448660
Axial piston pump Bosch Rexroth series A8VO, type code A8VO107LR3H1+A4FO40+A4FO22+A10VO28DR, material number R909448660. Axial piston unit: bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar (A8V). Operating mode: double pump (parallel design), open circuit (O).
- Number
- R909448660
- Type code
- A8VO107LR3H1+A4FO40+A4FO22+A10VO28DR
- Group
- A10VO 28
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909441122 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R909083090 | SOCKET HEAD CAP SCREW | 2 | ||
| R909430409 | WASHER | 2 | ||
| R909442364 | HYDRAULIC LINE Assembly parts list →L | 1 | ||
| R909441144 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R909830511 | AXIAL-PISTON PUMP | 1 | ||
| R909083090 | SOCKET HEAD CAP SCREW | 2 | ||
| R909430409 | WASHER | 2 | ||
| R909442095 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R909083090 | SOCKET HEAD CAP SCREW | 2 | ||
| R909430409 | WASHER | 2 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar | A8V |
| Operating mode | Double pump (parallel design), open circuit | O |
