Unit · A A4VSO 71
A A4VSO 71521806
Axial piston pump Bosch Rexroth series A4VSO, type code AA4VSO71, material number 521806. Nominal size: NG 71. Axial piston unit: swashplate design, variable, SAE nominal pressure 5100 psi (350 bar), maximum pressure 5800 psi (400 bar) (AA4VS). Operating mode: pump, open circuit (O).
- Number
- 521806
- Type code
- A A4VSO 71
- Group
- A4VSO 71
- Edition
- 12/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910925578 | BASE UNIT Assembly parts list →L | 1 | ||
| R910942723 | REGULATOR Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, SAE nominal pressure 5100 psi (350 bar), maximum pressure 5800 psi (400 bar) | AA4VS |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 71 | 71 |
