Unit · AXIAL-PISTON PUMP
AA11VLO260LG2S/11L-MSD07KXXX-SR902025077
Axial piston pump Bosch Rexroth series A11VO, type code AA11VLO260LG2S/11L-MSD07KXXX-S, material number R902025077. Nominal size: NG 260. Axial piston unit: swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar (A11V). Operating mode: pump, open circuit with charge pump (LO). Control device: with override pilot-pressure related positive control, with load-sensing (LG2S). Direction of rotation: viewed on drive shaft counter-clockwise (L). Drive shaft: splined shaft ANSI B92.1a‒1976 for single pump (S). Mounting flange: SAE J744 ‒ 4-hole (D). Working port: SAE pressure and suction port lateral, opposite, metric fastening thread according to DIN 13. Port thread, UNF with O-ring based on ISO 11926 (07). Standard/special version: special version (S).
- Number
- R902025077
- Type code
- AA11VLO260LG2S/11L-MSD07KXXX-S
- Group
- A11VLO 260
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| 1 | R902042952 | ROTARY GROUP Assembly parts list →L | 1 | |
| 2 | R902037373 | CONNECTION PLATE, LL Assembly parts list →L | 1 | |
| R909447095 | REGULATOR Assembly parts list →L | 1 | ||
| R909600261 | CONTROL Assembly parts list →L | 1 | ||
| R902015419 | CONTROL Assembly parts list →L | 1 | ||
| R902021367 | SEALING COVER Assembly parts list →L | 1 | ||
| R902039332 | BELL HOUSING Assembly parts list →L | 1 | ||
| R902224687 | HOLD-DOWN ELEMENT Assembly parts list →L | 1 | ||
| R902094196 | HOUSING | 1 | ||
| 11 | R902132714 | PIVOT PIN | 4 | |
| R909449670 | IMPELLER, LEFT-HAND ROTATATION | 1 | ||
| R909921095 | SETSCREW | 2 | ||
| R909153328 | SEALING NUTD | 2 | ||
| R909153364 | SCREW PLUGD | 4 | ||
| R909831387 | SOCKET HEAD CAP SCREW | 4 | ||
| R909831133 | O-RINGD | 1 | ||
| R909153378 | SCREW PLUGD | 1 | ||
| R913016375 | SLOTTED SPRING PIN | 2 | ||
| R909151259 | RETAINING RING | 2 | ||
| 30 | R909154024 | SCREW PLUG | 2 | |
| R909153371 | SCREW PLUG | 1 | ||
| R902600612 | BLEEDER VALVE | 2 | ||
| R909438015 | COVER Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar | A11V |
| Operating mode | Pump, open circuit with charge pump | LO |
| Size (NG) | 260 | 260 |
| Control device | with override pilot-pressure related positive control, with load-sensing | LG2S |
| Index | Size 145 … 260 | 1 |
| Direction of rotation | Viewed on drive shaft counter-clockwise | L |
| Drive shaft | Splined shaft ANSI B92.1a‒1976 for single pump | S |
| Mounting flange | SAE J744 ‒ 4-hole | D |
| Working port | SAE pressure and suction port lateral, opposite, metric fastening thread according to DIN 13. Port thread, UNF with O-ring based on ISO 11926 | 07 |
| Standard/special version | Special version | S |
