Unit · AXIAL-PISTON PUMP
A8VO120LAXKH2/80R1-VSG05F00X-SR902094599
Axial piston pump Bosch Rexroth series A8VO, type code A8VO120LAXKH2/80R1-VSG05F00X-S, material number R902094599. Axial piston unit: bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar (A8V). Operating mode: double pump (parallel design), open circuit (O). Direction of rotation: viewed on drive shaft, right (R). Transmission ratio (ndrive / nrotary groups): i = 1 (1). Service line ports: SAE fl ange ports A and A on opposite sides (metric fastening thread) SAE fl ange port S at rear (metric fastening thread) (5). Auxiliary pump: with integrated auxiliary pump Standard (F). Standard / special version: special version (S).
- Number
- R902094599
- Type code
- A8VO120LAXKH2/80R1-VSG05F00X-S
- Group
- A8VO 120
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902090043 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R902094602 | CONTROL Assembly parts list →L | 1 | ||
| R902021791 | COVER Assembly parts list →L | 1 | ||
| R902094569 | CONNECTION PLATE Assembly parts list →L | 1 | ||
| R902094603 | HYDRAULIC LINE Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable, nominal pressure 380 bar, maximum pressure 420 bar | A8V |
| Operating mode | Double pump (parallel design), open circuit | O |
| Direction of rotation | Viewed on drive shaft, right | R |
| Transmission ratio (ndrive / nrotary groups) | i = 1 | 1 |
| Service line ports | SAE fl ange ports A and A on opposite sides (metric fastening thread) SAE fl ange port S at rear (metric fastening thread) | 5 |
| Auxiliary pump | With integrated auxiliary pump Standard | F |
| Standard / special version | Special version | S |
