Unit · PUMP COMBINATION
A4VG280EP2+A4VG280EP2+A11VO145DRS+AZPGR902243038
Pump combination Bosch Rexroth series A4VG, type code A4VG280EP2+A4VG280EP2+A11VO145DRS+AZPG, material number R902243038. Nominal size: NG 280. Axial piston unit: swashplate design, variable, nominal pressure 450 bar, maximum pressure 500 bar (A4V). Operating mode: pump, closed circuit (G). Control device: proportional control, electric U = 24 V (EP2).
- Number
- R902243038
- Type code
- A4VG280EP2+A4VG280EP2+A11VO145DRS+AZPG
- Group
- A11VO 145
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902243035 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R902243036 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R902243037 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| 0510725181 | HYDRAULIC GEAR PUMPL | 1 | ||
| R909152538 | HEXAGON SCREW | 4 | ||
| R909152538 | HEXAGON SCREW | 4 | ||
| R909083086 | SOCKET HEAD CAP SCREW | 2 | ||
| R909436988 | WASHER | 4 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 450 bar, maximum pressure 500 bar | A4V |
| Operating mode | Pump, closed circuit | G |
| Size (NG) | 280 | 280 |
| Control device | Proportional control, electric U = 24 V | EP2 |
