Unit · AXIAL-PISTON PUMP
A4VG145EP/40+A10VNO85/53+A10V018/53+AZPFR902249527
Axial piston pump Bosch Rexroth series A4VG, type code A4VG145EP/40+A10VNO85/53+A10V018/53+AZPF, material number R902249527. Nominal size: NG 145. Axial piston unit: swashplate design, variable, nominal pressure 450 bar, maximum pressure 500 bar (A4V). Operating mode: pump, closed circuit (G). Connector for solenoids: without connector (only for purely hydraulic control) (0).
- Number
- R902249527
- Type code
- A4VG145EP/40+A10VNO85/53+A10V018/53+AZPF
- Group
- A10VNO 85
- Edition
- 01/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902249526 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R902502675 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R902502686 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| 9510290449 | HYDRAULIC GEAR PUMP | 1 | ||
| R909083708 | HEXAGON SCREW | 4 | ||
| R909083700 | HEXAGON SCREW | 2 | ||
| R909083058 | SOCKET HEAD CAP SCREW | 2 | ||
| R909430409 | WASHER | 4 | ||
| R909921512 | WASHER | 2 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 450 bar, maximum pressure 500 bar | A4V |
| Operating mode | Pump, closed circuit | G |
| Size (NG) | 145 | 145 |
| Connector for solenoids | Without connector (only for purely hydraulic control) | 0 |
