Unit · REGULATOR
R A4VS 125,180 FRG /30R902402761
Control Bosch Rexroth series A4VS, type code RA4VS125,180FRG/30, material number R902402761.
- Number
- R902402761
- Type code
- R A4VS 125,180 FRG /30
- Group
- A4VS 125
- Edition
- 07/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910993970 | ADJUSTING PIECE Assembly parts list →L | 1 | ||
| R910976948 | INTERMEDIATE PLATE Assembly parts list →L | 1 | ||
| R910962672 | CONTROL VALVE Assembly parts list →L | 1 | ||
| R910902489 | CONTROL VALVE Assembly parts list →L | 1 | ||
| R910836761 | NOZZLE | 1 | ||
| R910799998 | SOCKET HEAD CAP SCREW | 4 |
