Unit · CONTROL
V A4VSG 355 EM/30R902410056
Control Bosch Rexroth series A4VSG, type code VA4VSG355EM/30, material number R902410056. Nominal size: NG 355. Axial piston unit: swashplate design, variable, nominal pressure 5100 psi (350 bar), maximum pressure 5800 psi (400 bar) metric (A4VS). Operating mode: pump, closed circuit (G).
- Number
- R902410056
- Type code
- V A4VSG 355 EM/30
- Group
- A4VSG 355
- Edition
- 07/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902569327 | ADJUSTING PISTON | 1 | ||
| R910946945 | BEARING FLANGE | 1 | ||
| R910946948 | BEARING FLANGE | 1 | ||
| R910946946 | BALL SCREW ASSEMBLY | 1 | ||
| R910912673 | COUPLING | 1 | ||
| R910918201 | TAPERED-ROLLER BEARING | 2 | ||
| R910900853 | SHAFT SEALING RING | 2 | ||
| R910942904 | BEARING SLEEVE | 2 | ||
| R910257176 | SHIM RING | 1 | ||
| R909830312 | RETAINING RING | 1 | ||
| R910103381 | PARALLEL KEY | 1 | ||
| R910125482 | PARALLEL KEY | 1 | ||
| R910604976 | SOCKET HEAD CAP SCREW | 4 | ||
| R910118982 | SOCKET HEAD CAP SCREW | 4 | ||
| R909153365 | SCREW PLUG | 1 | ||
| R902650323 | R-RING | 2 | ||
| R910923831 | R-RING | 2 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 5100 psi (350 bar), maximum pressure 5800 psi (400 bar) metric | A4VS |
| Operating mode | Pump, closed circuit | G |
| Size (NG) | 355 | 355 |
| Series | Series 3, index 0 | 30 |
