Unit · CONTROL
V A6V M 500 EP2 /63-V017ER902421330
Control Bosch Rexroth series A6VM, type code VA6VM500EP2/63-V017E, material number R902421330. Nominal size: NG 500. Axial piston unit: bent-axis design, variable (A6V). Operating mode: motor (M). Control device: proportional control, electric (with HIRSCHMANN connector – without suppressor diode) U = 24 V (EP2). Sealing material: FKM (fluoroelastomer) (V). Working port: SAE working ports A and B at rear Flushing and boost-pressure valve, mounted 7 (017). Swivel angle sensor: electric swivel angle sensor (E).
- Number
- R902421330
- Type code
- V A6V M 500 EP2 /63-V017E
- Group
- A6VM 500
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902421332 | ADJUSTING PIECE Assembly parts list →L | 1 | ||
| R910975648 | CONTROL PART Assembly parts list →L | 1 | ||
| R910932571 | COVER Assembly parts list →L | 1 | ||
| R910925925 | INDUCTIVE POS.TRANSDUCER Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable | A6V |
| Operating mode | Motor | M |
| Size (NG) | 500 | 500 |
| Control device | Proportional control, electric (with HIRSCHMANN connector – without suppressor diode) U = 24 V | EP2 |
| Series | Series 6, index 3 | 63 |
| Sealing material | FKM (fluoroelastomer) | V |
| Working port | SAE working ports A and B at rear Flushing and boost-pressure valve, mounted 7 | 017 |
| Swivel angle sensor | Electric swivel angle sensor | E |
