Unit · AXIAL-PISTON PUMP
AA4VSO250DRG/30R-VPB13N00-SO508R902437957
Axial piston pump Bosch Rexroth series A4VSO, type code AA4VSO250DRG/30R-VPB13N00-SO508, material number R902437957. Nominal size: NG 250. Axial piston unit: swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar (A4VS). Operating mode: pump, open circuit (O). Directions of rotation: viewed on drive shaft Clockwise (R). Drive shafts: parallel keyed shaft DIN 6885 (P). Mounting flange: based on ISO 3019-2 (metric) 4-hole (B). Through drive: without through drive and auxiliary pump (N00). Special version no. 508.
- Number
- R902437957
- Type code
- AA4VSO250DRG/30R-VPB13N00-SO508
- Group
- A4VSO 250
- Edition
- 12/2019
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910988379 | BASE UNIT Assembly parts list →L | 1 | ||
| — | REGULATOR Assembly parts list →L | 1 | ||
| 61 | R902805709 | SHIPPING PROTECTION | 1 | |
| 62 | R902602206 | SEAL SCREW | 1 | |
| 63 | R902564145 | SHIPPING PROTECTION | 1 | |
| 81 | R909831377 | GUARD PLUG | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar | A4VS |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 250 | 250 |
| Series | Series 3, index 0 | 30 |
| Directions of rotation | Viewed on drive shaft Clockwise | R |
| Drive shafts | Parallel keyed shaft DIN 6885 | P |
| Mounting flange | Based on ISO 3019-2 (metric) 4-hole | B |
| Through drive | without through drive and auxiliary pump | N00 |
