Unit · CONTROL
V A6V M 250 HA1T /63-V020E -SO 10R902451417
Control Bosch Rexroth series A6VM, type code VA6VM250HA1T/63-V020E-SO10, material number R902451417. Nominal size: NG 250. Axial piston unit: bent-axis design, variable (A6V). Operating mode: motor (M). Control device: automatic control, high-pressure related with minimum pressure increase Δp ≤ approx. 10 bar (HA1). Override (only for HA): override, hydraulic, remote controlled, proportional (T). Sealing material: FKM (fluoroelastomer) (V). Working port: SAE working ports Without valve 0 A and B at side, opposite 02 (020). Swivel angle sensor: electric swivel angle sensor (E).
- Number
- R902451417
- Type code
- V A6V M 250 HA1T /63-V020E -SO 10
- Group
- A6VM 250
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902405430 | ADJUSTING PIECE Assembly parts list →L | 1 | ||
| R910945036 | CONTROL PART Assembly parts list →L | 1 | ||
| R910934340 | COVER Assembly parts list →L | 1 | ||
| R910927063 | INDUCTIVE POS.TRANSDUCER Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable | A6V |
| Operating mode | Motor | M |
| Size (NG) | 250 | 250 |
| Control device | Automatic control, high-pressure related with minimum pressure increase Δp ≤ approx. 10 bar | HA1 |
| Override (only for HA) | Override, hydraulic, remote controlled, proportional | T |
| Series | Series 6, index 3 | 63 |
| Sealing material | FKM (fluoroelastomer) | V |
| Working port | SAE working ports Without valve 0 A and B at side, opposite 02 | 020 |
| Swivel angle sensor | Electric swivel angle sensor | E |
