Unit · AXIAL-PISTON PUMP
AL A10VSO 71ED 72/32R-VSB32U01P -S1550R902480769
Axial piston pump Bosch Rexroth series A10VSO, type code ALA10VSO71ED72/32R-VSB32U01P-S1550, material number R902480769. Nominal size: NG 71. Axial piston unit: swashplate design, variable, nominal pressure 280 bar, maximum pressure 350 bar (A10VS). Operating mode: pump, open circuit (O). Control device: pressure cut-off electric U = 24 V electric negative control (ED72). Direction of rotation: viewed on drive shaft clockwise (R). Sealing material: FKM (fluorocarbon rubber) (V). Drive shaft: splined shaft standard shaft ISO 3019-1 (S). Mounting flange: ISO 3019-2; 4-hole (B). Port: SAE flange ports fastening thread, metric. top, bottom, opposite, with universal through drive with pulse damping (32). Through drive: only for port plate 22 and 32, 82-2 (A) 5/8 in 9T 16/32DP (U01).
- Number
- R902480769
- Type code
- AL A10VSO 71ED 72/32R-VSB32U01P -S1550
- Group
- A10VSO 71
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902480527 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| 2 | R902400578 | FLANGE COVER | 1 | |
| 3 | R902400590 | FLANGE COVER | 1 | |
| R902602011 | SEAL SCREW | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 280 bar, maximum pressure 350 bar | A10VS |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 71 | 71 |
| Control device | pressure cut-off electric U = 24 V electric negative control | ED72 |
| Series | Series 3, index 2 | 32 |
| Direction of rotation | Viewed on drive shaft clockwise | R |
| Sealing material | FKM (fluorocarbon rubber) | V |
| Drive shaft | Splined shaft standard shaft ISO 3019-1 | S |
| Mounting flange | ISO 3019-2; 4-hole | B |
| Port | SAE flange ports fastening thread, metric. top, bottom, opposite, with universal through drive with pulse damping | 32 |
| Through drive | Only for port plate 22 and 32, 82-2 (A) 5/8 in 9T 16/32DP | U01 |
