Unit · CONTROL
V A6V M 355 EZ2 /63-V017E -SO228R902494276
Control Bosch Rexroth series A6VM, type code VA6VM355EZ2/63-V017E-SO228, material number R902494276. Nominal size: NG 355. Axial piston unit: bent-axis design, variable (A6V). Operating mode: motor (M). Control device: two-point control, electric (with HIRSCHMANN connector – without suppressor diode) U = 24 V (EZ2). Sealing material: FKM (fluoroelastomer) (V). Working port: SAE working ports A and B at rear Flushing and boost-pressure valve, mounted 7 (017). Swivel angle sensor: electric swivel angle sensor (E). Standard/special version: special version (-S). Special version no. 228.
- Number
- R902494276
- Type code
- V A6V M 355 EZ2 /63-V017E -SO228
- Group
- A6VM 355
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R902495893 | ADJUSTING PIECE Assembly parts list →L | 1 | ||
| R910969829 | CONTROL PART Assembly parts list →L | 1 | ||
| R910939719 | COVER Assembly parts list →L | 1 | ||
| R902494277 | INDUCTIVE POS.TRANSDUCER Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable | A6V |
| Operating mode | Motor | M |
| Size (NG) | 355 | 355 |
| Control device | Two-point control, electric (with HIRSCHMANN connector – without suppressor diode) U = 24 V | EZ2 |
| Series | Series 6, index 3 | 63 |
| Sealing material | FKM (fluoroelastomer) | V |
| Working port | SAE working ports A and B at rear Flushing and boost-pressure valve, mounted 7 | 017 |
| Swivel angle sensor | Electric swivel angle sensor | E |
| Standard/special version | Special version | -S |
