Unit · AXIAL-PISTON PUMP
V-PUMPEA7V0160LRDS/60L-PZB01*G*R909422782
Axial piston pump Bosch Rexroth series A7V, type code V-PUMPEA7V0160LRDS/60L-PZB01*G*, material number R909422782.
- Number
- R909422782
- Type code
- V-PUMPEA7V0160LRDS/60L-PZB01*G*
- Group
- A7V 160
- Edition
- 07/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909410900 | ROTARY GROUP Assembly parts list →L | 1 | ||
| 2 | R909422780 | CONTROL | 1 | |
| R909650456 | CONTROL LENS, LEFT-HAND ROTATION | 1 | ||
| 4 | R909424996 | SEQUENCE VALVE Assembly parts list →L | 1 | |
| R909425281 | HOUSING | 1 | ||
| R909151694 | SCREW PLUGD | 2 | ||
| R909153075 | SETSCREW | 2 | ||
| R909152459 | SEALING NUTD | 2 | ||
| R909151694 | SCREW PLUGD | 1 |
