Unit · AXIAL-PISTON PUMP
A8VO80LR3DH2/60R1-PZG05K13R909442430
Axial piston pump Bosch Rexroth series A8VO, type code A8VO80LR3DH2/60R1-PZG05K13, material number R909442430.
- Number
- R909442430
- Type code
- A8VO80LR3DH2/60R1-PZG05K13
- Group
- A8VO 80
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909418512 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R909442431 | CONTROL Assembly parts list →L | 1 | ||
| R902117580 | TOOTHED WHEEL | 1 | ||
| R902099415 | FLANGE | 1 | ||
| R909152647 | O-RINGD | 1 | ||
| R909085478 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909150668 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909083086 | SOCKET HEAD CAP SCREW | 4 | ||
| R909083225 | SCREW PLUG | 2 | ||
| R909083758 | O-RINGD | 2 | ||
| R909152707 | SEALING NUTD | 1 | ||
| R909083500 | SETSCREW | 1 | ||
| R909083090 | SOCKET HEAD CAP SCREW | 2 | ||
| R909430409 | WASHER | 2 | ||
| R909085365 | O-RINGD | 1 | ||
| R909433183 | HYDRAULIC LINE Assembly parts list →L | 1 | ||
| R909433182 | HYDRAULIC LINE Assembly parts list →L | 1 | ||
| R909442435 | HYDRAULIC LINE Assembly parts list →L | 2 |
