Unit · AXIAL-PISTON PUMP
AA7V1000DRFERNGEST.R910825549
Axial piston pump Bosch Rexroth series A7V, type code AA7V1000DRFERNGEST., material number R910825549.
- Number
- R910825549
- Type code
- AA7V1000DRFERNGEST.
- Group
- A7V 1000
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| 40 | R910825573 | CONTROL Assembly parts list →L | 1 | |
| 40 | R910589896 | ADJUSTING PART Assembly parts list →L | 2 | |
| 50 | R910802069 | HOUSING | 1 | |
| 60 | R910713481 | ROTARY GROUP Assembly parts list →L | 1 | |
| 61 | R909153862 | SCREW PLUGD | 2 | |
| 61 | R909153815 | SCREW PLUGD | 2 |
