Unit · AXIAL-PISTON MOTOR
GE A6VLM 250 /61W-PZBR910925123
Axial piston motor Bosch Rexroth series A6VM, type code GEA6VLM250/61W-PZB, material number R910925123. Nominal size: NG 250. Axial piston unit: bent-axis design, variable (A6V). Drive shaft bearing: long-life bearing (L). Operating mode: motor (M). Direction of rotation: viewed on drive shaft variable (W). Drive shaft: splined shaft DIN 5480 (Z). Mounting flange: ISO 3019-2 4-hole (B).
- Number
- R910925123
- Type code
- GE A6VLM 250 /61W-PZB
- Group
- A6VLM 250
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910925124 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R910909810 | ADJUSTING PART Assembly parts list →L | 1 | ||
| R910909810 | ADJUSTING PART Assembly parts list →L | 1 | ||
| R902443566 | HOUSING | 1 | ||
| R909151694 | SCREW PLUGD | 1 | ||
| R909151979 | SCREW PLUGD | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable | A6V |
| Drive shaft bearing | Long-life bearing | L |
| Operating mode | Motor | M |
| Size (NG) | 250 | 250 |
| Direction of rotation | Viewed on drive shaft variable | W |
| Drive shaft | Splined shaft DIN 5480 | Z |
| Mounting flange | ISO 3019-2 4-hole | B |
