Unit · BASE UNIT
G A4VSG 250 'HD' M/11X-VZB10N00R910931855
Base unit Bosch Rexroth series A4VSO, type code GA4VSG250'HD'M/11X-VZB10N00, material number R910931855. Nominal size: NG 250. Axial piston unit: swashplate design (A4VSG).
- Number
- R910931855
- Type code
- G A4VSG 250 'HD' M/11X-VZB10N00
- Group
- A4VSG 250
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910931854 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R910989414 | CONNECTION PLATE Assembly parts list →L | 1 | ||
| R910963119 | INDICATING DEVICE Assembly parts list →L | 1 | ||
| R910963097 | STUD BOLT Assembly parts list →L | 1 | ||
| R902572930 | SOCKET HEAD CAP SCREW | 4 | ||
| R909153930 | SCREW PLUGD | 2 | ||
| R909156979 | SCREW PLUGD | 3 | ||
| R910962996 | O-RINGD | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design | A4VSG |
| Size (NG) | 250 | 250 |
