Unit · AXIAL-PISTON PUMP
A A4VSO 125 LR2 /22R-PPB13N00R910936376
Axial piston pump Bosch Rexroth series A4VSO, type code AA4VSO125LR2/22R-PPB13N00, material number R910936376. Nominal size: NG 125. Axial piston unit: swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar (A4VS). Operating mode: pump, open circuit (O). Directions of rotation: viewed on drive shaft Clockwise (R). Drive shafts: parallel keyed shaft DIN 6885 (P). Mounting flange: based on ISO 3019-2 (metric) 4-hole (B). Through drive: without through drive and auxiliary pump (N00).
- Number
- R910936376
- Type code
- A A4VSO 125 LR2 /22R-PPB13N00
- Group
- A4VSO 125
- Edition
- 10/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910936354 | BASE UNIT Assembly parts list →L | 1 | ||
| R910936160 | REGULATOR Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar | A4VS |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 125 | 125 |
| Directions of rotation | Viewed on drive shaft Clockwise | R |
| Drive shafts | Parallel keyed shaft DIN 6885 | P |
| Mounting flange | Based on ISO 3019-2 (metric) 4-hole | B |
| Through drive | without through drive and auxiliary pump | N00 |
