Unit · AXIAL-PISTON PUMP
A A10V O 71+DFEO/31R-PSC62K01 -SO200R910961696
Axial piston pump Bosch Rexroth series A10VO, type code AA10VO71+DFEO/31R-PSC62K01-SO200, material number R910961696. Nominal size: NG 71. Axial piston unit: swashplate design, variable, nominal pressure 280 bar (4100 psi), maximum pressure 350 bar (5100 psi) (A10V). Operating mode: pump, open circuit (O).
- Number
- R910961696
- Type code
- A A10V O 71+DFEO/31R-PSC62K01 -SO200
- Group
- A10VO 71
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910961601 | BASE UNIT Assembly parts list →L | 1 | ||
| R910947340 | INDUCTIVE POS.TRANSDUCER Assembly parts list →L | 1 | ||
| R902469008 | SEALING COVER Assembly parts list →L | 1 | ||
| 14 | R902534067 | FLANGE COVER | 1 | |
| 15 | R902400591 | FLANGE COVER | 1 | |
| 16 | R909153339 | SCREW PLUG | 1 | |
| 19 | R902449557 | FLANGE COVER | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design, variable, nominal pressure 280 bar (4100 psi), maximum pressure 350 bar (5100 psi) | A10V |
| Operating mode | Pump, open circuit | O |
| Size (NG) | 71 | 71 |
