Unit · REGULATOR
R A4VS 125/180 LR2 /30-VR910999902
Control Bosch Rexroth series A4VS, type code RA4VS125/180LR2/30-V, material number R910999902.
- Number
- R910999902
- Type code
- R A4VS 125/180 LR2 /30-V
- Group
- A4VS 125
- Edition
- 07/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910998097 | ADJUSTING PIECE Assembly parts list →L | 1 | ||
| R910988967 | INTERMEDIATE PLATE Assembly parts list →L | 1 | ||
| R910984429 | CONTROL VALVE Assembly parts list →L | 1 | ||
| R910903670 | SOCKET HEAD CAP SCREW | 4 |
