Unit · AXIAL-PISTON PUMP
A8VTO107LR3DS/60R1-NZG05K01-SR902035252
Axial piston pump Bosch Rexroth series A8VTO, type code A8VTO107LR3DS/60R1-NZG05K01-S, material number R902035252.
- Number
- R902035252
- Type code
- A8VTO107LR3DS/60R1-NZG05K01-S
- Group
- A8VTO 107
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909442568 | CONTROL Assembly parts list →L | 1 | ||
| R909434733 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R909442543 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R909442549 | HYDRAULIC LINE Assembly parts list →L | 1 | ||
| R909444325 | GEAR HOUSING | 1 | ||
| R909416121 | LOCKING RINGD | 1 | ||
| R902035248 | ROTARY GROUP HOUSING | 1 | ||
| R909444931 | CONNECTION PLATE | 1 | ||
| R909650796 | SEALD | 1 | ||
| R909444932 | CONNECTING PIECE | 1 | ||
| R909083419 | RETAINING RING | 1 | ||
| R913043034 | ROTARY SHAFT LIP SEALD | 1 | ||
| R909083829 | O-RINGD | 1 | ||
| R909083063 | SOCKET HEAD CAP SCREW | 6 | ||
| R909151979 | SCREW PLUGD | 2 | ||
| R909083019 | SOCKET HEAD CAP SCREW | 4 | ||
| R913009669 | STRAIGHT PIN | 2 | ||
| R902600656 | O-RINGD | 1 | ||
| R909086517 | O-RINGD | 1 | ||
| R909084134 | STRAIGHT PIN | 1 | ||
| R909085976 | SETSCREW | 1 | ||
| R909152459 | SEALING NUTD | 1 | ||
| R909083091 | SOCKET HEAD CAP SCREW | 6 | ||
| R909083026 | SOCKET HEAD CAP SCREW | 2 | ||
| R909086491 | SOCKET HEAD CAP SCREW | 2 | ||
| R909083763 | O-RINGD | 1 |
