Unit · AXIAL-PISTON PUMP
A8VTO80LRD/60R1-PZ05G*SV*R909419358
Axial piston pump Bosch Rexroth series A8VTO, type code A8VTO80LRD/60R1-PZ05G*SV*, material number R909419358.
- Number
- R909419358
- Type code
- A8VTO80LRD/60R1-PZ05G*SV*
- Group
- A8VTO 80
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909423525 | AXIAL-PISTON PUMP Assembly parts list →L | 1 | ||
| R909419029 | CONTROL Assembly parts list →L | 1 | ||
| R909426332 | TOOTHED WHEEL | 1 | ||
| R909439159 | FLANGE | 1 | ||
| R909152647 | O-RINGD | 1 | ||
| R909085478 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909150668 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909083086 | SOCKET HEAD CAP SCREW | 4 | ||
| R909083225 | SCREW PLUG | 2 | ||
| R909083758 | O-RINGD | 2 | ||
| R909152426 | SEALING NUTD | 1 | ||
| R909083500 | SETSCREW | 1 | ||
| R909086150 | HEXAGON SCREW | 2 | ||
| R909083830 | O-RINGD | 1 |
