Unit · AXIAL-PISTON PUMP
PA4VSG500HD/11X-VPH1**350N-SO385R910932052
Axial piston pump Bosch Rexroth series A4VSO, type code PA4VSG500HD/11X-VPH1**350N-SO385, material number R910932052. Nominal size: NG 500. Axial piston unit: swashplate design (A4VSG). Control device: hydraulic control, pilot-pressure related (HD).
- Number
- R910932052
- Type code
- PA4VSG500HD/11X-VPH1**350N-SO385
- Group
- A4VSG 500
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R910931893 | BASE UNIT Assembly parts list →L | 1 | ||
| R910931838 | CONTROL Assembly parts list →L | 1 | ||
| R910948831 | VALVE MOUNTING KIT | 1 | ||
| R910907074 | VALVE MOUNTING KIT | 1 | ||
| R910932055 | FLUSHING VALVE Assembly parts list →L | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Swashplate design | A4VSG |
| Size (NG) | 500 | 500 |
| Control device | Hydraulic control, pilot-pressure related | HD |
| Series | Series 1, index 1 | 11 |
