Unit · AXIAL-PISTON MOTOR
A6V107DA2FZ20636R909408655
Axial piston motor Bosch Rexroth series A6VM, type code A6V107DA2FZ20636, material number R909408655. Nominal size: NG 107. Axial piston unit: bent-axis design, variable (A6V). Control device: automatic control, speed related pSt/pHD = 3/100, hydraulic travel direction valve (DA).
- Number
- R909408655
- Type code
- A6V107DA2FZ20636
- Group
- A6V 107
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909410355 | ROTARY GROUP Assembly parts list →L | 1 | ||
| 2 | R909077711 | CONTROL Assembly parts list →L | 1 | |
| 3 | R909066741 | CONTROL LENS | 1 | |
| R909411052 | HOUSING | 1 | ||
| R909153815 | SCREW PLUG | 1 | ||
| 12 | R909151692 | SCREW PLUG | 1 | |
| 98 | R902166378 | SEAL KIT | 1 |
Parameters from the type code
| Item | Meaning | Code |
|---|---|---|
| Axial piston unit | Bent-axis design, variable | A6V |
| Size (NG) | 107 | 107 |
| Control device | Automatic control, speed related pSt/pHD = 3/100, hydraulic travel direction valve | DA |
