Unit · AXIAL-PISTON PUMP
A4VO125LCDS/A4VO56LRD/1*G*R909424966
Axial piston pump Bosch Rexroth series A4VO, type code A4VO125LCDS/A4VO56LRD/1*G*, material number R909424966.
- Number
- R909424966
- Type code
- A4VO125LCDS/A4VO56LRD/1*G*
- Group
- A4VO 125
- Edition
- 06/2020
| Pos. | Number | Name | Qty | Add to inquiry |
|---|---|---|---|---|
| R909423229 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R909410130 | ROTARY GROUP Assembly parts list →L | 1 | ||
| R909424660 | CONNECTION PLATE Assembly parts list →L | 1 | ||
| R909424659 | CONNECTION PLATE Assembly parts list →L | 1 | ||
| R909424693 | REGULATOR Assembly parts list →L | 1 | ||
| R909424986 | REGULATOR Assembly parts list →L | 1 | ||
| R909420840 | CONTROL Assembly parts list →L | 2 | ||
| R909410227 | CONTROL Assembly parts list →L | 2 | ||
| R909424704 | HYDRAULIC LINE Assembly parts list →L | 1 | ||
| R909420538 | HOUSING | 1 | ||
| R909416218 | HOUSING | 1 | ||
| R909414045 | ANTI-TWIST LOCK | 1 | ||
| R909414046 | ANTI-TWIST LOCK | 1 | ||
| R909424590 | FLANGE | 1 | ||
| R909431056 | INTERMEDIATE FLANGE | 1 | ||
| R909413679 | FLANGE Assembly parts list →L | 1 | ||
| R913009667 | STRAIGHT PIN | 1 | ||
| R909083023 | SOCKET HEAD CAP SCREW | 2 | ||
| R909157222 | SOCKET HEAD CAP SCREW | 4 | ||
| R909083021 | SOCKET HEAD CAP SCREW | 2 | ||
| R909156810 | SOCKET HEAD CAP SCREW | 4 | ||
| R909086574 | SOCKET HEAD CAP SCREW | 4 | ||
| R909085349 | SOCKET HEAD CAP SCREW | 2 | ||
| R909083254 | SPRING LOCK WASHER | 2 | ||
| R909085366 | O-RINGD | 1 | ||
| R909085364 | O-RINGD | 1 |
