PT-A4VG140EP3X2/32R-NTFXXF02XBRPH-S (R902251641)
CONTROL CARTRIDGE (42473)

CONTROL CARTRIDGE
(42473)


1

CONTROL SCREW
(40602)


2

DIFFERENTIAL PISTON
(13202)


3

CONTROLLER PIPE
(13203)


10

THRUST MEMBER
(21455)


12

COMPRESSION SPRING
(42474)


14

SETSCREW
(21457)


16

RING
(13204)


24

O-RING
(11174)


28

SEALING NUT
(10215)


29

SLOTTED SPRING PIN
(26350)


33

V-RING
(13082)


34

V-RING
(13205)



Return
