A4VG110EP2DP0TX/40MLND6V81FD4V8BD00-S (R902276711)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 110 cm³. Proportional control, electric U = 24 V. Pressure cut-off, with bypass. Fixed setting, hydraulic, mechanical. DEUTSCH molded connector, 2-pin – without suppressor diode. Without swivel angle sensor. Stroking chamber pressure port X₃ X₄. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: counter-clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 152-2/4. Splined shaft ANSI B92.1a–1976 1 3/8 in 21T 16/32DP. SAE working port A and B, on left side (45° left). Standard rotary group, boost pump integrated, standard internal gear pump. Filtration in the boost pump pressure line. Attachment filter with cold start valve and electric contamination indicator – DEUTSCH connector. Special version.
