AA10VO100DFR1/31R-PSC12N00-SO526 (R902420923)
FLUSHING VALVE (105295)

FLUSHING VALVE
(105295)


1

FLUSHING VALVE HOUSING
(105297)


2

FLUSHING PISTON
(105298)


3

REDUCTION THREADED JOINT
(105299)


5

COMPRESSION SPRING
(105300)


8

O-RING
(18405)


9

SEAL RING
(15642)


10

NOZZLE
(99704)


11

SCREW PLUG
(11292)


12

SCREW PLUG
(11918)


13

DOUBLE BREAK-OFF PLUG
(18990)


16

SEAL RING
(10991)



Return

The above diagrams belong to Rexroth www.boschrexroth.com
