A4VG110DA1DQ0T1/40MRND6A11FD4V8AD00-Y (R902121115)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 110 cm³. Automatic control, speed related U = 12 V. Pressure cut-off, with bypass. Fixed setting, hydraulic, mechanical. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 152-2/4. Splined shaft DIN 5480 W45×2×21×9g. SAE working port A and B, on left side (45° left). Standard rotary group, boost pump integrated, standard internal gear pump. High-pressure relief valve, direct operated, fixed setting, with low-pressure relief valve, fixed setting. Filtration in the boost pump pressure line. Ports for external boost circuit filtration (F_e and F_a). Standard version with installation variants.
