A4VG085EV2DP000/40+A11VO75LRS/10 (R902157480)
Set of 2 pumps:
1. Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 085 cm3. Series 40.
2. Axial Piston Variable Pump A11VO. Swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar. Open circuit. Size, ≈ displacement Vg maks. 75 cm3. Control unit: power control with override
1. Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 085 cm3. Series 40.
2. Axial Piston Variable Pump A11VO. Swashplate design, variable, nominal pressure 350 bar, maximum pressure 400 bar. Open circuit. Size, ≈ displacement Vg maks. 75 cm3. Control unit: power control with override
The above diagrams belong to Rexroth www.boschrexroth.com
