A4VG110EP20P000/40MRND6T21UD4V8AE00-Y (R902157263)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 110 cm³. Proportional control, electric U = 24 V. Without pressure cut-off, without bypass. DEUTSCH molded connector, 2-pin – without suppressor diode. Without swivel angle sensor. Without additional function. Without DA control valve. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 152-2/4. Splined shaft ANSI B92.1a–1976 2 in 15T 8/16DP. SAE working port A and B, on left side (45° left). Standard rotary group, without boost pump. High-pressure relief valve, direct operated, fixed setting, with low-pressure relief valve, fixed setting. External boost pressure supply. Standard version with installation variants.
