AAA10VO45DFR/50R-PSC64N00-MESSE (R910930048)
BASE UNIT (134712)

BASE UNIT
(134712)


1

PUMP HOUSING
(16355)


2

CONNECTION PLATE
(134710)


3

DRIVE SHAFT
(110995)


5

TAPERED-ROLLER BEARING
(13223)


6

TAPERED-ROLLER BEARING
(13224)


7

RETAINING RING
(13229)


8

SHAFT SEALING RING
(13226)


10

ADJUSTMENT SHIM
(13222)


11

SCREW PLUG
(16357)


12

STOP SCREW
(15983)


13

NUT
(15839)


14

CAP NUT
(15840)


15

SCREW PLUG
(11369)


16

SOCKET HEAD CAP SCREW
(15994)


18

DOUBLE BREAK-OFF PLUG
(18990)



Return

The above diagrams belong to Rexroth www.boschrexroth.com
