A4VG140HWDL7/32R-NSF02F021S-S (R902074135)
CONTROL UNIT (32866)

CONTROL UNIT
(32866)


1

HOUSING
(32867)


2

CONTROL SLEEVE
(23337)


3

CONTROL SHAFT
(23338)


4

SPRING BUSH
(12805)


5

COMPRESSION SPRING
(12728)


6

ECCENTRIC PIN
(14567)


7

COVER
(23339)


8

RING
(32868)


9

LEVER
(12681)


10

NECK
(32869)


11

SEAL BUSHING
(21135)


12

SOCKET HEAD CAP SCREW
(10505)


13

SOCKET HEAD CAP SCREW
(10506)


14

SOCKET HEAD CAP SCREW
(10698)


15

SOCKET HEAD CAP SCREW
(12810)


16

SEALING NUT
(10215)


17

O-RING
(10508)


18

O-RING
(10509)


19

O-RING
(10771)


20

O-RING
(10450)


21

O-RING
(15512)


22

O-RING
(10227)


23

O-RING
(10370)


24

PLUG
(17025)


25

PLUG
(13073)


27

SHIM RING
(17166)


28

NEEDLE-ROLLER
(23340)


29

STRAIGHT PIN
(12694)


30

PLUG
(11172)


33

O-RING
(10513)


34

HEXAGON NUT
(21136)


35

SWITCH
(21677)


36

SPRING DISK
(21139)


37

SPRING SLEEV
(21140)


38

STOP PIN
(21141)


39

COMPRESSION SPRING
(21138)
