A4VG145EP4DP0R0/40MLND6A11BC2V8AS00-0 (R902118772)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 145 cm³. Proportional control, electric with manual override and spring return U = 24 V. Pressure cut-off, with bypass. Fixed setting, hydraulic, mechanical. DEUTSCH molded connector, 2-pin – without suppressor diode. Without swivel angle sensor. Neutral valve U = 12 V and ports X₃ , X₄ for stroking chamber pressure. Without DA control valve. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: counter-clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 152-2/4. Splined shaft DIN 5480 W45×2×21×9g. SAE working port A and B, on left side (45° left). Standard rotary group, boost pump integrated, large internal gear pump. Flange SAE J744: diameter- 127-2 (C), mounting- horizontally, code- C2. Hub for splined shaft: diameter- 1 3/8 in 21T 16/32DP, code- V8. High-pressure relief valve, direct operated, fixed setting, with low-pressure relief valve, fixed setting. Filtration in the boost pump suction line.
