AH A10V O 74 DFLR/31R-PWC62N00P -S2087 (R902449981)

Axial piston variable pump A10V, swashplate design, open circuit, nominal pressure 280 bar, maximum pressure 350 bar. Series 31. High-speed version. Geometric displacement 74 cm3. Pressure-flow power control. Drive splined shaft ANSI B92.1a, higher torque; limited suitability for through drive. Mounting flange ISO 3019-1 (SAE) 2-hole. SAE flange ports according to J518 Working ports UNF. Fastening thread UNF; lateral top bottom, for through drive. Without through drive. DEUTSCH - molded connector, 2-pin, without suppressor diode.
1

BASE UNIT
(118587)

Group »


2

CONTROL VALVE
(19862)

Group »


3

CONTROL VALVE
(13212)

Group »


5

SIDE MARKER RING
(116448)


6

SOCKET HEAD CAP SCREW
(19886)


7

VALVE PLATE
(19863)

Group »


8

SEAL
(10001)


9

PIPING
(19864)

Group »


10

PIPING
(19866)

Group »


11

POWER DIAGRAM
(147882)


14

SCREW PLUG
(11371)


15

NOZZLE
(10619)


60

SAFETY CAP
(13891)



Return

The above diagrams belong to Rexroth www.boschrexroth.com
