A4VG110EP20PR00/40MLND6T11UC2S7CE40-Y (R902222143)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 110 cm³. Proportional control, electric U = 24 V. Without pressure cut-off, without bypass. DEUTSCH molded connector, 2-pin – without suppressor diode. Electric swivel angle sensor (DWS20-1, 3-pin). Without additional function. Without DA control valve. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: counter-clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 152-2/4. Splined shaft ANSI B92.1a–1976 1 3/4 in 13T 8/16DP. SAE working port A and B, on left side (45° left). Standard rotary group, without boost pump. Flange SAE J744: diameter- 127-2 (C), mounting- horizontally, code- C2. Hub for splined shaft: diameter- 1 1/4 in 14T 12/24DP, code- S7. Standard version with installation variants.
