A4VG085ET5DP000/40MRNC6Z81F0000AB00-0 (R902245614)

Axial piston variable pump A4VG, swashplate design, nominal pressure 450 bar, maximum pressure 500 bar. Pump, closed circuit. Geometric displacement 085 cm³. Electric control, direct operated, two pressure reducing valves (DRE) U = 12 V. Pressure cut-off, with bypass. Fixed setting, hydraulic, mechanical. DEUTSCH molded connector, 2-pin – without suppressor diode. Without swivel angle sensor. Without additional function. Without DA control valve. Series 40. Metric ports according to ISO 6149 with O-ring seal, metric fastening thread according to DIN 13. Direction of rotation: clockwise (viewed on drive shaft). Sealing material: NBR (nitrile rubber), shaft seal in FKM (fluoroelastomer). Mounting flange SAE J744 127-2/4. SAE working port A and B, on left side (45° left). Standard rotary group, boost pump integrated, standard internal gear pump. Without through drive. High-pressure relief valve, direct operated, fixed setting, with low-pressure relief valve, fixed setting. Filtration in the boost pump pressure line. Attachment filter with cold start valve and electric contamination indicator – DEUTSCH connector.
